3.6
Lubrication and maintenance operations
3.6.20 Engine air intake check Check the engine air intake always on the machine which is parked on a flat and solid surface, with the machine engine and battery disconnecter off. Engine air intake check procedure: •
Check the hole (1) in the engine bonnet (2).
•
The hole (1) must be without any dirt.
•
Open the engine bonnet (2).
•
Check the condition of brushes (3); in case they are excessively worn, replace them.
•
Close the engine bonnet (2).
Check the engine air intake when the machine is parked on a flat and solid surface with the engine and battery disconnecter off. Wear the prescribed personal protective equipment when checking the engine air intake. There is a risk of burns from the hot parts of the engine.
2
1
C452061
3
452062 Keep the hole in the engine bonnet clean. Keep the brushes in an undamaged state. There is a risk of damaging the engine.
160
F80W
