3.6
Lubrication and maintenance operations
Procedure for lubrication of the paving width setting mechanism: •
The procedure is identical for the left and right side of the screed.
•
Set the maximum paving width on both screed sides.
•
Remove lubricating grease residues and dust from the screed extension guide (1).
•
Apply the lubricating grease on the screed extension guide (1).
•
Dismount the protective covers and clean the grease nipples (2) on the linear hydraulic motors (3).
•
Connect the grease gun to the grease nipples.
•
Lubricate the bearings until the lubricant starts to flow out.
•
Mount the protective covers on the grease nipples (2) on the linear hydraulic motors (3).
2
2
1 3
D451125A
Lubricate the machine when it is parked on a flat and solid surface, the engine and the battery disconnector are off and the gas bottle is closed. When lubricating the machine, use the prescribed protective equipment. There is a risk of burns from the hot parts of the screed. There is a risk of injury due to the fall of the screed.
Front wheel suspension lubrication procedure: • Dismount the protective cover and clean the grease nipple (1). •
Connect the grease gun to the grease nipple (1).
•
Lubricate the bearing until the lubricant starts to flow out.
•
Mount the protective cover on the grease nipple (1).
Lubricate the front wheel suspension when the machine is parked on a flat and solid surface, the engine and the battery disconnector are off and the gas bottle is closed. When lubricating the machine, use the prescribed protective equipment.
154
1
452041
F80W
