3.6
Lubrication and maintenance operations
3.6.5
Cleaning the hopper, outlets and conveyor
Before applying the anti-adherent solution remove gross dirt from the conveyor, material outlets and the hopper of the machine.
1
3
Clean the driver’s stand always on the machine which is parked on a flat and solid surface, with the machine engine and battery disconnecter off. Cleaning procedure: •
Make sure the material hopper (1) is empty.
•
Apply the anti-adherent solution on the material hopper (1), material outlets (2) and conveyor (3).
•
Use a scraper to remove material residues from the material hopper walls (1).
•
Use a scraper to remove material residues from the material outlets (2).
•
Use a scraper to remove material residues from the conveyor (3).
•
Start the engine.
•
Activate the function of conveyor start by shifting the operating mode controller (17) to the lower position and the controller (18) on the main dashboard to remove dirt from the hopper area.
•
After removing dirt from the hopper area disable the switch (18) and the operating mode switch (17) functions.
•
Turn off the engine and disconnect the battery disconnecter.
•
Apply the anti-adherent solution on the material hopper (1), material outlets (2) and conveyor (3).
2 451117
STOP
12V
0V
18 17
14V
452032
Caution! There is a risk of injury during cleaning. Remove dirt from the hopper area using a scraper only with the engine and battery disconnecter off. Use the prescribed protective equipment during cleaning.
Use the prescribed anti-adherent solution according to Chapter 3.2.4. It is prohibited to use diesel oil instead of an anti-adherent solution.
138
F80W
