Operation of the screed
2.6.3
Setting the paving width STOP
12V
The machine is equipped with a left (43) and right (44) screed extension frame for setting the paving width.
0V
14V
The required paving width can be set using the controls (2) and (3) on the dashboard. The basic screed width is 800 mm (31.5 in), and each of the extendible screed extension is 250 mm (9.8 in) wide. The adjustable range of the paving width corresponds to the total width of both extendible screed extensions and amounts to 500 mm (19.7 in). The paving width can be adjusted in a maximum to minimum range value. The paving width in the standard model of the machine is: •
Minimum paving width without reduction plates 800 mm (31.5 in)
•
Maximum paving width without reduction plates: 1,300 mm (51.2 in)
3
2
52
Paving width with reduction plates is: •
Minimum paving width with reduction plates (centre of the machine): 250 mm (9.8 in)
•
Maximum paving width with reduction plates: 750 mm (29.5 in)
51 44
Paving width with mechanical extension is: •
Minimum paving width with mechanical extension: 1150 mm (45.3 in)
•
Maximum paving width with mechanical extension: 1650 mm (65 in)
452025
43
451091A
Setting the paving width: Procedure for setting the required paving width on the left side of the screed: •
To increase the paving width on the left side, turn the paving width switch (2) to the left and hold it.
•
Once released, the paving width switch (2) returns to the middle position and the screed stops in the required position.
•
To decrease the paving width on the left side, turn the paving width switch (2) to the right and hold it.
•
Once released, the paving width switch (2) returns to the middle position and the screed stops in the required position.
•
Check the required setting of the paving width on the left side by checking the position on the left paving width indicator (51).
