Adjusting the endless belts 10. CHECK 10.1 Position of upper and lower arms Check the clearance between upper or lower arm and right or left hand wall. – Clearance = min. 3 mm
55
10.2 Aligning upper and lower arms Check whether lower (D) and upper (G) arms are in line. – The arms must overlap over a width of at least 8 mm.
D
G 56
10.3 Tightening the bearing for roller 7 Tighten 6 bolts M10 (A) on left and right hand side with 45 Nm.
(Fig. 57-58)
A
57
A
58
