Adjusting the endless belts 8. SETTING 8.1 Adjusting roller 7 – closed tailgate Slacken the bolts M10 (A) on either side of the machine. Adjust roller 7 by means of the threaded pins on left (B) and right (C) hand side. Adjustment direction If the belts drift to the left in the guides of roller 7, raise the roller on the left hand side or lower it on the right hand side, so that the belts run in the middle between the guides.
A 40
Note! B The differences in length between the pins on right and left hand side must not exceed 15 mm. r
– Retighten the bolts M10 (A) on either side of the machine. (Fig. 40, 41, 42) 41
8.2 Checking the adjustments – step 5 Repeat all tests conducted in the step "5. Checking the belt guides".
C
Shut down the machine.
42
8.3 Relieving the belts Relieve the belts hydraulically (see operating instructions, chapter on maintenance).
