CLAAS COMBINE VARIANT 260 VARIANT280 ADJUSTING THE ENDLESS BELTS Assembly instructions Manual_DE_EN_

Adjusting the endless belts 5. CHECKING THE BELT GUIDES

Note! Check each of the following points before performing the step "6. Adjustment - closed tailgate".

5.1 Close the tailgate Unlock securing lever (M). Run the engine with low speed (300-350 rpm) to close the tailgate. Then allow the engine to run another 2 minutes with low speed (300-350 rpm). Shut down the machine. Danger! Always shut the engine down and pull the ignition key out before working or performing adjustment work on the tailgate and in the baling chamber.

Note! The following tests must only be conducted with the engine shut down!

299 498.0 - ABA Riemen - VRT 260/280
