Adjusting the endless belts 4. INITIAL POSITION – TAILGATE OPEN 4.1 Clearance between wall and lower arm Measure the clearance between left (E) and right (F) hand wall and lower arm (D). The clearance between arm and walls must be at least 3 mm. If the clearance is less than 3 mm the lower arm needs to be adjusted accordingly. See item "4.4 Longitudinal adjustment of lower arm".
D
E
(Fig. 6, 7) 6
D
F
7
4.2 Aligning upper and lower arms Check whether lower (D) and upper (G) arms are in line: the arms must overlap over a width of at least 8 mm. – After aligning the arms continue with item "5.1 Close the tailgate".
D
– If the arms are not in line continue with following steps. G Note! 8
The lower arm effects the belt guide when the tailgate is open. The upper arm effects the belt guide when the tailgate is closed. (Fig. 8)
4.3 Relieving the belts Relieve the belts hydraulic in order to be able to perform the following step. (see operating instructions, chapter on maintenance)
58
ABA Riemen - VRT 260/280 - 299 498.0
