844/642 Telehandler
BATTERY
STEP 10
STEP 12
1
2
G0505010
G0505003
Install the positive (+) battery cable on the positive (+) post of the battery.
Install the battery access cover (1) and secure with four screws (2). IMPORTANT: Be sure the battery cables are routed correctly and secured away from sharp edges, hot or moving objects.
WARNING
STEP 13
Always install the negative (-) battery cable last so you do not cause a spark at the battery. A spark can cause the battery to explode and c au se pe rs ona l inju ry or da ma ge to th e machine.
1
STEP 11
2
G0505005
Install the top battery access cover (1) and secure with two thumbscrews (2). Close the tool box door.
G0505006
Install the negative (-) battery cable on the negative () battery post. IMPORTAN T: Be su re th e ca bles a nd batte r y terminals are clean and tight.
PRINTED IN U.S.A.
302-4
