844/642 Telehandler
ELECTRICAL STEP 32
STEP 30
1
2 2
G0705139
Conn ect the positive (+) test lead to th e relay terminal (tan/red wire) of the park brake switch. With the key switch and park brake switch in the ON position, the multimeter should read 12 to 13 volts.
G0705084
Install the instrument panel (1) using the four screws (2).
If there is no voltage, replace the park brake switch. If there is 12 to 13 volts, but no voltage at Step 24, replace the tan/red wire between the switch and the relay.
STEP 31
G0705085
Move the park brake switch to the OFF position. The multimeter should read 0 volts. If there is no voltage, but there was 12 to 13 volts at Step 25 replace the lift cylinder proximity switch. If there is 12 to 13 volts, replace the park brake switch.
PRINTED IN U.S.A.
301-17
