844/642 Telehandler
ELECTRICAL KEY SWITCH AND STARTER SWITCH TESTS
STEP 10
STEP 12
G0705129
Connect the positive (+) test lead to the starter terminal of the starter relay. Turn the key switch to the ON position an d p ress the star ter button. The multimeter should read 12 to 13 volts.
1
2
G0705092
Remove the retaining nut from the key switch (1) and the rubber button guard from the starter button (2).
If there is no voltage, proceed to the next step. If there is 12 to 13 volts and the starter does not turn over the engine, repair or replace the starter and/or the starter solenoid.
STEP 13 2
STEP 11
1
1
G0705084
G0705130
Turn the key switch to the OFF position. Connect the positive (+) test lead to the ignition terminal of the starter relay. Turn the key switch to the ON position and press the starter switch. The multimeter should read 12 to 13 volts. If there is no voltage, proceed to the next step. If there is 12 to 13 volts, but the starter does not turn over the engine, turn the key switch to the OFF position and replace the starter relay. Install the wire on the fuel shutoff solenoid.
G0705117
Remove the four screws (1) from the instrument panel (2). Pull the instrument panel outward to gain access to the wire harnesses and switches. PRINTED IN U.S.A.
