844/642 Telehandler
ELECTRICAL
STEP 6
STEP 8
G0705098
G0705128
Connect the positive (+) test lead to the bottom terminal (#2) of the relay socket. Turn the key to the ON position. The multimeter should read 12 to 13 volts.
Connect the positive (+) test lead to the batter y terminal of the starter relay. The multimeter should read 12 to 13 volts.
If there is no voltage, proceed to Step 12. If there is 12 to 13 volts, but the relay does not work, replace the relay.
If there is no voltage, replace the wire between the starter relay battery terminal and the starter. If there is 12 to 13 volts, proceed to the next step.
STEP 9 STARTER AND STARTER RELAY TESTS STEP 7
G0605153
Remove the wire from the fuel shutoff solenoid.
G0705136
Connect the positive (+) test lead to the battery terminal of the starter. The multimeter should read 12 to 13 volts. If there is no voltage, clean or replace the positive (+) battery cable between the starter and the battery. If there is 12 to 13 volts, proceed to the next step.
PRINTED IN U.S.A.
301-11
WARNING When the test involves turning over the engine or starting the engine, use test leads long e nough t o re a d t he mult im e te r f rom t he o pe r a t ors s e a t o r s t a n di ng cl e a r o f th e machine.
