844/642 Telehandler
ENGINE
STEP 4
STEP 7
G0605072
G0605096
Remove the top hood. Complete Steps 25 through 32 of Section 800 for the correct procedures.
Open the radiator drain valve at the bottom of the ra d ia t o r. D ra i n th e c o o la n t in t o a n a p p r o ve d container.
STEP 5 STEP 8
G0705072
Remove the mid section hood. Complete Steps 40 through 46 of Section 800 for the correct procedures.
G0605097
Open the engine block drain valve and drain the coolant into an approved container.
STEP 6 NOTE: Attaching a hose to the drain valves will help direct the coolant to the container. 1
STEP 9 After all the coolant is removed, close both drain va l ve s. R e c y c le o r d i s p o s e o f c o o l a n t i n a n environmentally safe manner.
2
G0705029
Loosen the hose clamp (1) and remove the 90° rubber elbow (2) from the turbo inlet. Install a cap on the turbo inlet.
