GENERAL TABLE OF CONTENTS MANDATORY SAFETY SHUTDOWN PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 RELIEVING HYDRAULIC PRESSURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 ENGINE REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 ENGINE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SPECIAL TORQUE VALUES U.S. Value Metric Value RH Engine Mount Bracket Bolts ............................................. 175 to 190 lb.-ft.......................... 235 to 260 Nm LH Engine Mount Bracket Bolts .................................................. 69 to 78 lb.-ft............................ 94 to 106 Nm RH Engine Mount Center Bolt ................................................ 285 to 320 lb.-ft.......................... 385 to 435 Nm Transmission to Engine Case Bolts ............................................ 40 to 45 lb.-ft..............................54 to 61 Nm Torque Converter Flex Plate Bolts.............................................. 33 to 37 lb.-ft..............................45 to 50 Nm Alternator Mounting Bracket Bolts .............................................. 56 to 64 lb.-ft..............................77 to 87 Nm Alternator Pivot Bolt and Nut ...................................................... 56 to 64 lb.-ft..............................77 to 87 Nm Alternator Flange Bolts ............................................................... 25 to 29 lb.-ft..............................34 to 39 Nm Fan Bearing Mounting Bolts ....................................................... 50 to 57 lb.-ft..............................68 to 77 Nm Fan Mounting Bolts .................................................................... 20 to 23 lb.-ft..............................27 to 31 Nm Fan Shroud Bolts ....................................................................... 12 to 14 lb.-ft..............................16 to 18 Nm Fan Guard Bolts ......................................................................... 12 to 14 lb.-ft..............................16 to 18 Nm Washer Bottle Bracket Bolts and Nuts ........................................ 16 to 21 lb.-ft..............................22 to 28 Nm
