844/642 Telehandler
INTERMEDIATE BOOM STEP 7
STEP 5 3
1
2
Alt= to hide template information Alt+ to display template information
1
3
2
G0505065
G1624MP
Loosen and remove the bolts (1) and lockplates (2) from the two side slide pads on the rear of the intermediate boom.
Loosen and remove the two bolts and lower side slide pad and shim from the front of the outer boom section.
Remove the two side slide pads and shims (3) from the rear of the intermediate boom.
STEP 8
STEP 6
G1626MP
Loosen and remove the two bolts and washers securing the hose tray bracket to the intermediate boom. Lower the hose tray and hose tray bracket.
G1645MP
Use a hoist and lifting strap around the intermediate boom section, pul the intermediate boom from the outer boom section approximately 12 inches (30 cm).
STEP 9
G1627MP
Loosen and remove the two bolts and upper side slide pad and shim from the front of the outer boom.
