844/642 Telehandler
Alt= to hide template information Alt+ to display template information
SINGLE CHAIN REPLACEMENT
STEP 28
STEP 31
G1660MP
G1660MP
Remove the grease fitting from the sheave pin. Remove the sheave pin from the roller bearing.
Place the roller bearing assembly between the sections of the mount, then insert the pin. Be sure the retainer bolt holes are lined up.
STEP 29 STEP 32
Remove the roller bearing.
STEP 30
G1659MP
Install the retainer bolt and nut through the pin and tighten. Reposition the single chain over the sheave pulley.
G1646MP
The roller bearing and sheave should be assembled before installing. Press the roller bearing into the sheave, apply grease to the inside of the roller bearing, then insert the inner ring into the roller bearing.
PRINTED IN U.S.A.
STEP 33 Reinstall the inner boom section, see Section 703 of this manual for the correct procedure.
705-5
