844/642 Telehandler
INNER BOOM
STEP 37
STEP 39 Reinstall the extend cylinder into the boom. See Section 610 of this manual for correct procedure.
STEP 40 Start the engine and check boom operation in a clear area.
STEP 41 Shut down the engine and check for hydraulic fluid leaks. Correct any leakage problems found. G1638MP
Reinstall the three bolts and washers to secure the single chain clevis block to the outer boom. Use Loctite 271 (red) Thread Lock (or equivalent) on the threads of the bolts.
STEP 38
G1657MP
Reinstall the double chain to the outer boom using the nuts. See Section 702 “Leaf Chain Adjustment Procedure” in this manual to apply the final torque to the double chain assembly.
