844/642 Telehandler
BOOM ASSEMBLY
STEP 3
NOTE: If only the boom pivot shaft is to be replaced, it will not be necessary to disconnect any hydraulic lines or lift cylinders from the boom. Connect an overhead lifting device to the rear of the boom. Use the lifting device to take up the weight of the boom from the pivot shaft. Remove the pivot shaft retainer bolt from the end of the shaft. Use a large brass drift and heavy sledge hammer or a hydraulic ram pusher arrangement to drive the shaft approximately half way out. Lubricate the new pivot shaft with antisieze grease. Install the new shaft into place. Using the old pivot shaft as a pilot, install the retainer bolt and nut. G0605057
Remove two of the extend cylinder mounting bracket bolts from the top rear of the outer boom section.
STEP 6
STEP 4
G0605053
Install a lifting strap around the front of the inner boom. Connect it to a second hoist and apply upward pressure.
G0605051
Install two 4000 lb. lifting brackets (or equivalent) and bolt to the top rear of the outer boom section.
STEP 7
STEP 5
G0505076
Remove the bolt and hydaulic hose support block from the two center hydraulic hoses.
G0605052
Con nect two e qual len gth chains to th e liftin g brackets. Apply upward pressure with an adequate size hoist until the chains are tight.
