844/642 Telehandler
Alt= to hide template information Alt+ to display template information
LIFT CYLINDER REMOVAL STEP 42
STEP 39
Base the adjustment of the eccentric pins on the following example: If the left-hand (LH) cylinder extends farther than the right-hand (RH) cylinder, you could potentially change the RH cylinder to raise higher by rotating its eccentric pin so that the “mark” points more towards the front of the machine. However, if you find the RH eccentric pin “mark” is already pointing towards the front of the handler machine, you could change the LH cylinder to not raise as high by rotating its eccentric pin to point more towards the rear of the machine. G0505060
Remove the rear hood. Complete Steps 10 and 11 of Section 800 for the correct procedures.
STEP 43
STEP 40
G0505081
Remove the three bolts that secure the eccentric pin to the mounting flange. G0505075
Remove the radiator covers. Complete Steps 14, 15 and 16 of Section 800 for the correct procedures.
STEP 44
STEP 41
Dashed lines indicate threaded hole locations
With “mark” here, cylinder is in “highest” position G0705089
With “Mark” here, cylinder is in “lowest” position
Using a pipe wrench, rotate the eccentric pin in the desired direction.
Mark indicates high side of eccentric pin G0705131
Examine eccentric pins on both sides of the machine to determine their current adjustment. PRINTED IN U.S.A.
