844/642 Telehandler
Alt= to hide template information Alt+ to display template information
LIFT CYLINDER REMOVAL
STEP 21
STEP 24 To aid in installing the lift cylinder rod (upper) end, obtain a round metal bar with a diameter just small enough to allow easy insertion through the rod end. It should also be short enough to fit between the lift cylinder mounts on the outer boom but longer than the width of the lift cylinder rod end. This temporary pivot pin will hold the spacers in position while the lift cylinder is secured to the boom with the actual rod end pivot pin.
STEP 25 G0505081
Install three bolts securing the eccentric pin to the chassis. 1
STEP 22
2
G0505096
Insert the temporary pin (1) throught he lift cylinder rod end and put a spacer (2) on each end of the pin.
STEP 26 G0505087
If installing the right lift cylinder, remove the cap and plug from the hydraulic oil return line and connect the return line to the hydraulic cooler.
STEP 23
G0505097
Using the chain hoist and lifting strap, position the lift cylinder in the cylinder mount.
G0505078
Remove the caps and plugs from the lift cylinder hydraulic lines and connect the two hydraulic lines to the lift cylinder. PRINTED IN U.S.A.
