844/642 Telehandler
Alt= to hide template information Alt+ to display template information
LIFT CYLINDER REMOVAL
STEP 3
STEP 5
G0505060
G0605012
Remove the rear hood. Complete Steps 10 and 11 of Section 800 for correct procedures.
R e m o ve th e t h r e e w i n d o w r e t a i n e r s a n d th e operator’s right side window.
STEP 4
STEP 6
G0505075
G0505083
Remove the radiator cover that corresponds to the cylinder to be removed. Complete Steps 14, 15 and 16 of Section 800 for the correct procedures.
Using a chain hoist and lifting strap, position the lifting strap to support the weight of the lifting cylinder when the upper pivot pin is removed. Apply upward pressure to remove slack in the lifting strap.
NOTE: If removing the left lift cylinder perform Step 5.
STEP 7
1
2
G0505085
Remove the bolt (1) and the retainer washer (2) from both sides of the upper pivot pin. PRINTED IN U.S.A.
609-2
