844/642 Telehandler
TILT CYLINDER
STEP 4
STEP 6
G1527MP
G1529MP
Using a chain hoist and lifting strap, position the lifting strap around the tilt cylinder and apply upward pressure.
Remove the upper pivot pin from the tilt cylinder. Use care not to damage the grease fitting while removing the pivot pin.
STEP 5
IMPORTANT: Protect the chrome finish on the cylinder rod at all times. Damage to surface of the rod can cause premature seal failure.
STEP 7
G1528MP
Remove the retainer bolt and nut from the pivot pin. G1530MP
Remove the rod end of the cylinder from the bracket first, then raise the chain hoist and remove the base end of the cylinder.
PRINTED IN U.S.A.
604-2
