844/642 Telehandler
HYDRAULICS
STEP 100
STEP 102
2 1
G0505014
G0805067
Move the park brake switch to the OFF position. The pressure gauge should read 400-425 psi (27-29 bar) when the park brake is released.
Remove the hose (1) from port IN (2) on the flow divider. Install a 1000 psi (69 bar) pressure gauge between the hose and IN port.
If the pressure is less than 400-425 psi (27-29 bar), but was at 400-425 psi (27-29 bar) when the park brake switch was ON, repair or replace the park brake in the front axle.
STEP 103
If the pressure is 400-425 psi (27-29 bar), but the park brake will not release, repair or replace the park brake solenoid valve and repeat Steps 98 and 100 before replacing or repairing the park brake in the front axle.
STEP 101
Start the engine and run at 1000 RPM. The pressure gauge should read 400-425 psi (27-29 bar). If the pressure is 400-425 psi (27-29 bar) replace the flow divider. If the pressure is less than 400-425 psi (27-29 bar), proceed to the next step.
STEP 104
G0805070
G0805068
Shut off the engine. Remove the pressure gauge from port PB and install the hose on the port.
Shut off the engine. Remove the pressure gauge and reconnect the hose to the IN port.
