844/642 Telehandler
HYDRAULICS
STEP 52
EXTENSION CYLINDER COUNTERBALANCE VALVE QUICK TEST STEP 55
G0805063
Replace the boom extend relief valve.
STEP 53
G0805055
Install a 5000 psi (345 bar) pressure gauge and hose on the “MP” test port of the flow divider.
Repeat Step 51. If the pressure is less than 3000 psi (207 bar), repair or replace the extend/retract control valve.
STEP 56 Start the engine and run at 1000 RPM. Extend the boom approximately 6 feet (2 meters). Watch the pressure gauge as the boom is slowly retracted, the gauge should read 1500 psi (103 bar).
STEP 54
If the pressure is less than 1500 psi (103 bar), proceed to the next step.
1
If the pressure is more than 1500 psi (103 bar), proceed to Step 60. 3
2
G0805036
Shut off the engine. Remove the pressure gauge (1) from the bulkhead fitting (2) and install the cylinder extend hose (3) on the fitting.
PRINTED IN U.S.A.
601-26
