844/642 Telehandler
HYDRAULICS
STEP 37
TILT CYLINDER COUNTERBALANCE VALVE DIRECT TEST STEP 39 3
1 G0505046
Star t the engine and run at 1000 RPM. Tilt the attachment mount up until the tilt cylinder reaches the end of its stroke and hold the joystick in the TILT UP position. The pressure gauge should read 3000 psi (207 bar). If the pressure is less than 3000 psi (207 bar) go to Step 30 of the Tilt Cylinder Direct Test. If the pressure is 3000 psi (207 bar), proceed to the next step.
2
G0805027
Shut off the engine. Install a 5000 psi (345 bar) pressure gauge and hose (1) between the tilt cylinder rod end (tilt down) port (2) and the supply hose (3).
STEP 40
STEP 38 Watch the pressure gauge as the attachment mount is slowly tilted down. The pressure gauge should read 1500 psi (103 bar) as the attachment mount is moving downward. If the pressure is less than 1500 psi (103 bar), proceed to the next step. G0805028
Start the engine and run at 1000 RPM. Watch the pressure gauge as the attachment is slowly tilted DOWN. The pressure gauge should read 1500 psi (1 03 ba r) a s th e a ttach men t mou nt is mov in g downward. Shut off the engine. If the pressure is more or less than 1500 psi (103 bar) proceed to the next step.
PRINTED IN U.S.A.
601-22
