844/642 Telehandler
FRONT AXLE
RELIEVING HYDRAULIC PRESSURE
STEP 3
2 1
G0505055
Remove the bolt (1) and retaining pin (2) from the lower pivot pin on the frame leveling cylinder.
G0505013
1. Fully retract the telescoping boom. 2. Raise the telescoping boom far enough to be able to remove the axle out from under the frame.
STEP 4
3. Turn the keyswitch to the OFF position to shut down the engine. (See above Mandatory Safety Shutdown Procedure.) 4. Move the frame leveling joystick several times to relieve hydraulic pressure in that circuit.
STEP 2
G0505056
Remove the lower pivot pin from the frame leveling cylinder.
STEP 5
G0605047
Place wood blocks under both tilt stops on the rear of the machine, to prevent the frame from rotating when the frame leveling cylinder is disconnected.
G0605001
While supporting the fender, loosen and remove the four bolts and nuts from the fender bracket. Remove the fender from the machine.
PRINTED IN U.S.A.
503-2
