844/642 Telehandler
REAR AXLE
STEP 30
STEP 32 1 2
G0605028
G0505052
Reinstall the driveshaft to the transmission and to the rear axle using the bolts and lock washers.
Reinstall the retainer pin (1) and bolt (2) in the lower pivot pin and tighten.
NOTE: Use Loctite 271 Thread Lock equivalent) on the ends of the bolts.
STEP 33
(or
STEP 31
G0605047
Remove the wood blocks under both tilt stops on the rear of the machine. G0505049
Using a pry bar, extend the stabilizer cylinder rod enough to install the lower pivot pin. Be sure to align the retainer bolt holes.
