844/642 Telehandler
REAR AXLE
STEP 3
STEP 6
1
2
G0505052
G0605028
Remove the bolt (1) and retainer pin (2) from the lower stabilizer pivot pin.
Disconnect the driveshaft from the transmission by removing the four bolts and lock washers. Remove the driveshaft from the machine.
STEP 4 STEP 7
G0505049
Remove the lower pivot pin from the stab ilizer cylinder.
G0605033
Mark the two hydraulic hoses for correct assembly. Loosen and remove the two hydraulic hoses from the steering cylinder.
STEP 5
STEP 8 Install caps and plugs on all hoses and hydraulic fittings to prevent con tamina ting the hydrau lic system.
G0605029
Disconnect the driveshaft from the rear axle by removing the four bolts and lock washers.
PRINTED IN U.S.A.
502-2
