844/642 Telehandler
TRANSMISSION STEP 31
STEP 28
2
1
G0705055
G0705063
Place a suitable jack under the engine, closest to the transmission. Raise the jack to support the weight of the engine when the transmission is removed.
Remove the bolt securing the battery ground cable (1) and the chassis ground cable (2) to the right side of the transmission.
STEP 29
STEP 32
G0705056
G0705062
Attach lifting chains to the transmission as shown. Attach the lifting chain to the hoist, apply enough upward pressure to support the transmission.
Remove the two bolts securing the left side mounting bracket to the transmission.
STEP 33 STEP 30
G0705035
Loosen the lock nuts from both transmission mount bolts.
G0705027
Remove the lower bell housing bolts.
PRINTED IN U.S.A.
501-6
