Removal & Refitment of Air Cleaner C. Cleaning Primary Element a.
Tap Primary Element with palm of your hand, NOT ON HARD SURFACE.
b.
Clean element with compressed air (below 130 kPa or 1.3 Bar). Hold nozzle next to inner surface, and move up and down pleats
DO NOT direct air against outside of element, as it might force dirt through to inside. c.
Inspect element before reinstalling.
Cleaning Primary Element
D. Washing Primary Element DO NOT wash element in fuel oil, oil, gasoline or solvent. DO NOT use compressed air to remove water from element. E. Inspecting Element a.
Hold a bright light inside element and check carefully for holes. Discard any element which shows the slightest hole.
b.
Be sure outer screen is not dented. Vibration would quickly wear a hole in filter.
c.
Be sure rubber sealing surfaces are in good condition on both ends. If damaged, replace element.
d.
Before you install Primary Element, clean the inside of air cleaner housing & unloader valve with a damp cloth.
e.
Ensure that dust unloader valve is facing downward. (With 30 Deg. Vertical axis)
f.
Install Primary Element & cover and shut bonnet.
F. SERVICE INSTRUCTIONS 1.
Check functioning of auto unloader of the dust collector regularly.
2.
Paper element of air cleaner should be cleaned with compressed air every 300 hrs. or earlier if required.
3.
Paper element of air cleaner should be replaced after every 2 cleanings or 900 hrs. or even earlier if required.
4.
Safety Cartridge should be replaced after every 900 hrs. or earlier if required.
G. STORING ELEMENT If element is not installed on tractor, seal element in a plastic bag and store in its original shipping container to protect against dust and damage.
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
B-27
