Removal & Refitment of Fender Removal & Refitment of Fender 1.
Using the special tool - Rail & Trolley Jack - support both rear axle. Apply Tractor parking brakes and place wedges to hold the rear wheels.
2.
Remove rear wheels of RH and LH side to access fenders.
3.
First remove the battery cable from its negative terminal & then remove battery cable from positive terminal.
4.
Disconnect fender wiring harness & remove from fender clamps.
5.
Loosen the fender mounting bolts (A).
6.
Hold the fender (B) firmly before attempting its removal.
The fender needs to be held in place with external support. Improper / inadequate supporting/holding the fender in place during its removal can cause injury. 7.
Refit the fender in the reverse sequence of removal.
Align the fender resting area equally and properly, before tightening the fender mounting nuts.
B-18
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
