Hydraulics 8.
Dis-assemble pipe clamps (L) by removing hardware and free the pipes off the bracket.
NOTE:
Before removing the pipes and connector, keep an oil collection tray below the auxiliary valve. After removal of connectors from auxiliary valve, take care to see that open ports of the auxiliary valve are properly plugged.
9.
Take out the two pipes (a & b) connected to auxiliary valve ports A1 & B1 by loosening the respective connectors.
10.
Remove Hose Auxiliary-valve P Port to Adapter P Port (M) by removing banjo bolt.
NOTE:
11.
Disconnect Hose Auxiliary-valve C Port to Adapter V Port (O) & Hose Auxiliary-valve T Port to Adapter T Port (N) by removing banjo bolt from adapter fitted on C & T ports.
12.
Loosen adapter (P&Q) from C & T ports and immediately plug the ports. Preserve the adapters and washers.
13.
At this stage Auxiliary valve can be removed from the mounting bracket for replacement by removing mounting bolts.
NOTE:
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
After removal of Banjo bolt from auxiliary valve, take care to see the open ports of the auxiliary valve are properly plugged.
Do not fit repaired auxiliary valve on the tractor. It is recommended to replace the complete auxiliary valve with cable assembly as a single unit.
I-39
