Hydraulics 16.
REMOVE, INSPECT AND INSTALL HYDRAULIC PISTON AND CYLINDER
1.
Remove Hydraulic Lift Unit as per the guided procedure as given in point no.11.
2.
Remove position and draft control linkages levers by loosening lock clips and washers.
3.
Remove two allen screws (A) & (B) to loosen the cylinder.
4.
Remove bolt (C) of bracket lubrication (D) and take it out.
5.
Remove cylinder assembly (E).
6.
Insert a long wood dowel or brass drift through cylinder opening to remove piston (F).
7.
Inspect all part for wear or damage. Check piston and cylinder for cracks or scoring. Replace as necessary.
Always use new seals. Old or damaged seals will leak.
I-32
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
