Hydraulics 15.
REMOVE, INSPECT AND INSTALL HYDRAULIC LIFT ARMS, ROCKSHAFT, ROCKER ARM, SEAL
1.
Remove Hydraulic Lift Unit as per the guided procedure as given in point no.11.
2.
Remove position and draft control linkages levers by loosening lock clips and washers.
3.
Rotate lift arms to access and remove setscrew (A) in crank (B).
4.
Remove snap ring (C) and arm (D) from opposite side of control levers on hydraulic.
NOTE:
Index parts to hydraulic with a punch mark before disassembly, to aid in correct alignment of these parts during assembly. Slightly tap lift arms to take out.
I-30
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
