Hydraulics 7.
Remove cam (J) and allen set screws (k).
8.
Loosen the allen set screw (L) of crank (M) and remove control lever support assembly by loosening bolts (N) and take out control lever support assembly.
9.
Remove roll pin (O) of cam (P) and snap ring.
10.
Remove capscrew (Q) of tie rod (R) and pin assembly (S).
NOTE:
11.
Reverse the dismantling procedure for assembly and installation.
NOTE:
12.
I-28
Inspect bushings for wear or damage. Replace as necessary.
Apply thread sealant to allen set screws during assembly.
Adjust hydraulic lift unit position and draft sensing feedback linkages.
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
