Splitting Between Engine & Transmission 23.
Dismantle the bolts which are connecting engine & clutch housing.
24.
Move the engine assembly away from tractor.
REJOINING THE TRANSMISSION
ENGINE
ASSEMBLY
AND
1.
Follow the reverse sequence of Splitting for rejoining the Engine assembly with the Transmission.
2.
Align the engine with housing.
Do not forcibly fit and tighten the mounting bolts of engine to clutch housing until the two mounting faces meet. Forcible tightening of bolts can result in serious damage to both Engine and clutch housing. Clutch housing needs to be held in place with external support. Check the freeplay of clutch and brake pedals. NOTE :
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
First align the PTO input shaft in the pilot bearing. Align PTO damper and PTO input shaft splines. Turn the flywheel and main shaft hollow shuttle section at the same time while pushing the Engine towards clutch housing. Allow the splines of clutch plate to align with those on the main shaft hollow shuttle section.
B-9
