Steering 6.
Further tap the rod till the piston comes out.
7.
Inspect the piston seal and bearing ring for wear or cracks.
8.
Remove wear or damaged seal or ring and install with new one. If these seals or O'Rings damaged, this will result into external leakages / free wheeling problem.
Steering Cylinder Refitment 1.
After installing new seals and o’ring on piston and cylinder head, tap gently by plastic hammer the rod to align it to cylinder housing face mounting bolt.
2.
Tighten the allen screw of cylinder head to cylinder housing as per the specified torque. (i.e.25Nm / 18 lb.ft.)
NOTE: Whenever dismantling of steering cylinder for inspection/checking always replace piston seal, head cover seals, rod seals, wiper ring and O’Ring (Seal Kit).
H-16
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
