Electrical System
6. ALTERNATOR DO’S AND DONT’S DO’s
7.
Increase the speed to 3000 rpm. The warning lamp should not glow and ammeter should shown charging current. Oil pressure should be 1.0 to 3 kgs/cm2.
8.
Run the Alternator at 5000 rpm. Adjust the load so that Terminal voltage is between 13.0 to 13.5 Volts. The Ammeter should read the rated output.
9.
Run the Alternator at 6003 rpm, and adjust the loads to 18 Amps. The volt meter should read 14.1 – 14.6 Volts.
10.
Disconnect the Air pipe at the Vacuum pump, install Vacuum gauge. Run Alternator at 5,000 RPM speed. After 35 seconds the Vacuum reading should read 500 mm/Hg.
11.
Close the solenoid valve, the Vacuum pump gauge should read the rated Vacuum in 3 minutes at 5,000 RPM.
12.
Check for Vacuum leak : Stop the drive (both main drive and oil pump). There should not be any drop in vacuum for 15 seconds.
5.
ROUTINE MAINTENANCE
•
Keep the alternator clean.
•
Ensure that the ventilation slots are clear.
•
Check and ensure that mounting bolts are tightened properly.
•
Ensure that the belt on the alternator is in good condition.
•
Check the belt tension and ensure that it is neither too slack nor too tight.
•
Adjust the belt deflection to be 10-15 mm at the longest point when pressed at midway between pulleys.
•
Check the brush length after every 60,000 km.
•
Ensure correct level of electrolyte in the battery.
•
Check the general condition of the battery.
•
Grease battery terminals with petroleum jelly. DONT’s
Do ensure that all electrical connections are clean and secure.
Do not dis-assemble the Alternator without removing the brush box assembly.
Do ensure that no electrical connection in the circuit including the battery is open.
Do not run the Alternator with the battery disconnected.
Do observe correct polarity, i.e. connect negative to negative and positive to positive. Otherwise, Alternator will be damaged.
Do not disconnect any lead of Alternator / Regulator with the engine in running condition.
Disconnect all Alternator terminals, while carrying out welding jobs on the vehicle.
Do not disconnect battery cables while the engine is running.
Disconnect the battery earth cable before removing the Alternator. 35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
G-25
