Electrical System 5.
FUSE BOX
The fuses protecting various circuits are mounted on the fuse box. The blown fuse will be indicated by failure of the particular system and can be confirmed by a continuity test. Before replacing blown fuse, inspect the wiring of the circuit for evidence of short circuit or any other fault which may have caused the fuse to blow. a.
Use correct type of fuse as shown on the fuse box cover.
b.
4 extra fuse links (one each) have been provided in the side fuse box cover. To remove this extra fuse from cover, press the link from contact point and push up in the direction of arrow marked on the cover. The fuse is located at LH side behind clutch pedal. Press plastic cover of the fuse box from top and bottom. The fuse cover will come out. If no fault can be detected and another fuse blows, have the equipment examined.
c.
d.
G-18
While refitting the fuse box cover care should be taken that clicking sound after fitting is heard. This ensures proper fitting of fuse box cover.
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
