Electrical System 2. Instrument Cluster
12 1
11
2
10
9 3
8
4
7
5 A.General The various Instruments gauges and switches are mounted on the instrument panel and scuttle assembly. The panel is secured by four screws on the scuttle assembly under the steering wheel. The operator can easily pay attention on the gauges and indicators and can reach to the switches and control while driving.
The operator must be thoroughly acquainted with the location and use of all instruments and controls regardless of experience, must read operators manual carefully before attempting to operate the tractor.
G-10
6 The Instrument Cluster is a descriptive unit that gives the user various indications about the working of the tractor and its various features. It consists of the following: 1. High Beam Indicator 2. LH / RH Turn Signal Indicator 3. Coolant Temperature Gauge 4. Fuel Level Gauge 5. Engine RPM Meter 6. Hour Counter 7. Engine Low Oil Pressure Gauge 8. Voltmeter 9. Battery Charge Indicator 10. 4WD Indicator 11. Parking Brake Indicator 12. Heater Indicator
