Differential Lock System 2.
Removal
a.
Remove Differential lock arrangement as per the procedure given in differential section.
b.
Remove differential lock pedal shaft (A) by removing spring pin (B).
c.
Use Special Tool (C) to remove spring pin.
d.
Remove fork spring lock pin (D).
e.
Hold spring and differential lock fork and pull differential cross shaft from RH side.
Removal of Differential Lock Shaft
Special Tool Removal of Differential Lock Shaft Pin
E-48
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
