Differential DIFFERENTIAL LAYOUT
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12.
Spline Shaft Pinion Differential Case Differential Case Bull Pinion Brake Shaft LH Bevel Gear Differential LH Gear Crown Wheel Differential Pinion Shaft Bevel Gear Differential RH Bull Gear Rear Axle Bull Pinion Brake Shaft RH Differential Housing Assembly
1.
Theory of Operation
The power from Spline Shaft (1) drive the Gear Crown Wheel (6). This in turn rotate Differential Housing (12). The power from differential housing flows through differential pinion (2) and then to Bevel Gear Differential (5/8). Bevel Gear drives the Bull Pinion (4/11). The Bull Pinion Shaft end matches with Bull Gear (9). This results in rotation of Axle Shaft (10). The Differential Housing Assembly consists of two Bevel Gear (LH & RH), two pinion and one shaft. When tractor takes a turn, one axle moves faster than other. This results in rotation of differential pinion to rotate on it’s own axis, and they roll over bevel gear and thus producing differential action. 35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
E-33
