Fuel System (C)
Cleaning, Inspection and Repair
1.
Clean out the tank thoroughly. Use clean fuel. Remove any signs of rust or corrosion.
2.
Check the tank for leaks.
3.
Ensure that the filler cap air vent is open and clean.
4.
Check the ‘Tank unit’ Fuel gauge sender is working properly.
(D)
Installation
1.
Reverse the removal procedure.
2.
Fill the tank with clean fuel and bleed the system in the following sequence.
(E)
FUEL TAP (VALVE) The Fuel Tap (1-2) is located between the Feed Pipe from tank to filter. The Screw type Valve arid Seal Assembly has two positions : off and on The fuel is allowed to flow while the valve is screwed out and vice versa. Remove the fuel cock and blow with compressed air to clean it. Replace it after cleaning and check for any leakage.
Fig.2
C-96
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
