Cooling System
Fig. 5 1. Radiator
d.
Unscrew the generator mounting bolt & nut, loose the nut, bolt of generator adjustment brace. Slide oft the generator belt.
e.
Loosen the inlet hose clamp which clamps the hose to the radiator inlet tube and work the hose free from the tube.
f.
Disconnect the battery earth lead.
g.
Loosen the outlet hose clamp which clamps the hose to the water pump and work the hose free from the pump. Slacken the two hose clips then remove the thermostat by pass hose.
h.
Lift the fan housing clear of the tractor.
i.
Remove the nut and setscrew which secures the adjustable pulley flange to the pulley hub and unscrew the flange from the hub. Slide off the drive belt.
j.
Unscrew the four nuts (1-7) from the water pump mounting studs.
k.
Withdraw the water pump as far as possible along the mounting studs and towards the radiator.
7.
THERMOSTAT : The Blocker type Thermostat is located in Thermostat Housing (2-7). The Thermostat controls the Engine operating temperature. When the Engine is cold the Thermostat is closed, preventing circulation of Coolant until it reaches operating temperature. The thermostat is set to open at 82OC (180OF)
NOTE:
When the Thermostat fails in the open position, the Engine runs too cold. Thereby the Cylinder Sleeves get glazed, leading to excessive consumption of Lubricating Oil. A Cold running Engine is damaged by combustion gas. ‘Blow by’, Crankcase condensation resulting in sludge formation in the Oil, High wear and corrosion of Engine parts and rapid clogging of the positive Crankcase ventilation system.
Do not to remove the Thermostat from Tractors for any reason whatsoever except to replace a defective thermostat. b. Fig. 7
C-84
Removal 1.
Drain the cooling system.
2.
Loosen the clamps on the radiator upper hose and work the hose clear of the thermostat housing.
3.
Remove the three capscrews (1-12) from the thermostat housing (2-12) and withdraw the thermostat.
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
