Maintenance and service work 3.13 Filling up engine oil OIL
Caution!
B
Too much or incorrect engine oil can result in engine damage! ☞ Do not add engine oil above the MAX mark of the oil dipstick ☞ Use only the specified engine oil
Environment! Use a suitable container to collect the engine oil as it drains and dispose of it in an environmentally friendly manner!
☞ Fill up the engine oil as follows:
max min
A
Fig. 43 : Filling up diesel engine oil
• • • • • • • • •
Clean the area around oil filler cap B with a lint-free cloth Open filler cap B Pull out the oil dipstick and wipe it with a lint-free cloth Fill in engine oil Wait a moment until all the oil has run into the oil sump Check the oil level A Fill up if necessary and check the oil level again Close filler cap B Completely remove all oil spills from the diesel engine
Notice! Have the oil changed by an authorised workshop! • Oil change intervals – see Maintenance plan (overview) on page 3-5
3-16
Serv-HB 40702 – Edition 2.0 * 407-02s0322_Wartung.fm
