Rear left working light (optionally on the right

3 4 5 6

1

23 7 3

2

22 21 8

9

10

11

24 25 26 27 12 11

20 19 18 17

29

28 9

13

14

15

16

1.1 Machine outside view

Pos. Description

1 Front hooks for loading/tying down the machine (left/right) 2 Headlights with turn indicators 3 Left/right rearview mirrors 4 Front right working light (option) 5 Front numberplate fixture (option) 6 Rotating beacon (option) 7 Front left working light (standard) 8 Rear numberplate fixture (option) 9 Reflector (depending on version) 10 Fuel tank filler inlet

11 Turn indicator/brake/rear light 12 Rear left working light (optionally on the right) 13 Socket – oil preheater under the engine cover (option) 14 Engine cover lock 15 Hydraulic oil tank filler inlet 16 Hydraulic connections (additional control circuit, option) 17 Rear hooks for tying down the machine (left/right on the frame) 18 Trailer coupling (option) Autohitch coupling (option) 19 Reflectors (2 x on rear end of machine, 2 x on rear light bracket) 20 Socket – trailer lights (option) 21 Eye hook1 for installing/removing the cab

22 Hydraulic connections (option) (unpressurised return, leak oil line) 23 Front-edge protection 24 Hydraulic connections 3rd control circuit (additional control circuit as an option) 25 Door lock

26 Lock for hinged side window 27 Wheel chock

28 Rear hooks for loading/tying down the machine (left/right) 29 Rearview mirror for trailer coupling (option)

1. Eye hooks are for removing the cab only, and may not be used for crane handling the machine
