Maintenance work Every 10 s/h
“A” 1st Inspection1 at 100 s/h
“B” every 500 s/h2 2nd Inspection
“C” every 1500 s/h once a year
• Air intake line (diesel engine air filter and cooling system)
●
●
●
●
●
• Engine lubrication (diesel engine – filter)
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
• Hydraulic system/telescopic boom (flexible lines and rams)
●
●
●
●
●
• Quick couplers, additional control circuit, 3rd control circuit, tipping trailer connection (option)
●
●
●
●
●
• Brake system (flexible lines and cylinders)
●
●
●
●
●
• Air conditioning – flexible lines, compressor, condensor, attachment (option)
●
●
●
●
●
For service and maintenance work on the attachment, please refer to the operation and maintenance manual of the attachment manufacturer as well.
Leakage check (
):
15
• Fuel lines fuel tank • Cooling system (diesel engine and hydraulic oil radiator) • Steering system (flexible lines and steering rams)
16 16
6
Serv-HB 40702 – Edition 2.0 * 407-02s0321_Wartungsplan.fm
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16.
Maintenance work Every 20 s/h
Delivery inspection
3.4 Maintenance plan (overview)
Operator/driver
Work to be performed once after the first 100 s/h. This work must be performed by an authorised workshop for warranty claims to be acknowledged. Work after the first 500 s/h (2nd Inspection) must be performed by an authorised workshop for warranty claims to be acknowledged. Replace filter insert as indicated by the indicator light, however at least every 12 months or 1500 s/h. When working in an acidic environment, replace the filter every 500 s/h! When using biodegradable oil: drain the condensation water in the hydraulic oil tank every 500 s/h, in any case before the cold season. Have the brake fluid (LHM) replaced every 2 years by an authorised workshop Have the coolant replaced every 2 years by an authorised workshop Depending on operation and dust conditions, it can be necessary to clean the radiator more frequently. Have the V-belts replaced after 2 years at the latest by an authorised workshop Depending on operation and dust conditions, it may be necessary to replace the fine-dust filter more frequently Replace the dehumidifier every 2 years or after maintenance and repair work on the refrigerating circuit Have the slide plates (minimum thickness 8 mm) adjusted and replaced by an authorised workshop only Lubricate more often (once a day) in case of heavy work Lubricate attachment according to manufacturer’s instructions! Replace flexible fuel leak oil lines every 2 years Replace flexible lines every 6 years (UVV, DIN 20066 part 5)
