Specifications 2.12 Trailer couplings: trailer weight/drawbar load Optional trailer coupling (see control mark in machine documentation) Self-propelled work machine according to Directive 70/156/EEC
Gross drawGross trailer weight bar load rating rating in kilograms (kg) (kg)
Trailer without brakes
750
Trailer with brakes (1 braked axle)
3500
Trailer with brakes (all axles braked)
8000
Trailer with hydraulic or pneumatic brakes
11250
Max. authorised load of towing gear
4000
1.
10001
10001
Taking into account the gross rear axle weight rating and the gross weight rating of the machine
Notice! With a trailer coupled, the machine must not transport any material on public roads. Only the transport of machine attachments is allowed! Get informed on and follow the legal regulations of your country!
2.13 Sound levels, noise Sound power level
dB(A)
Measured value
101.5
Guaranteed value
104
Driver-perceived noise level
80
Notice! Measurement of sound power level according to EC Directive 2000/14 EC and according to the modified EC Directive 2005/88 EC. Driver-perceived noise level measured according to EC Directives EN ISO 11201. Measurements performed on asphalted surface.
2-12
Serv-HB 40702 – Edition 2.0 * 407-02s_Tech_Daten.fm
