Specifications Main fuse box with relays in the engine compartment F025
F029
K005 Fig. 30: Main fuse box
F028
K007
F026
K029
The main fuse box is located in the engine compartment in front of the radiator F027 Fuse
Rated current (A)
Protected circuit
F025
80 A
Preheating-time control relay
F026
50 A
Starting relay
F027
30 A
Fuel preheater (option)
F028
80 A
Main fuse – board
F029
80 A
Main fuse
Relay no.
Protected circuit
K005
Preheating time lag relay
K007
Start high current relay
K029
Excess fuel, minus compensation switching relay
Electric units
2-10
Description
Power
Alternator
14 V 80 A
Starter
12 V 2.0 kW
Battery
12 V 74 Ah
