Specifications 2.4 Drive Variable displacement pump, boost pump Variable displacement pump H1 Design (Sauer-Danfoss) Displacement Max. operating pressure (high pressure)
Automotive, infinitely variable hydrostatic axial-piston gearbox 0 – 45 cm³/rev 450 bar
Starting engine speed
1250 – 1350 rpm/50 bar HP
Max. engine droop speed
2600 rpm/300 – 350 bar HP
Boost pump integrated in variable displacement pump Design
Gear pump
Displacement
12 cm³/rev
Charging/boost pressure Control
30 bar at max. rpm Electronic
Driving direction
Electrohydraulic control
Inching (brake/inching pedal)
Electric (potentiometer)
Variable displacement motor1
20 kph (30 kph option)
Variable displacement motor
Design (Sauer-Danfoss) Capacity
110 cm³/rev
PCOR pressure (pressure relief valve)
180 bar
Drive ranges (forward/reverse)
1st drive range: 0 – 7 kph 2nd drive range: 0 – 20 kph
Traction force2
44 kN
Traction force3
40 kN
1. 2. 3.
Serv-HB 40702 – Edition 2.0 * 407-02s_Tech_Daten.fm
Axial piston motor flanged onto transfer gearbox (rear axle)
With flush valve and speed sensor With tyres 12.5-18 With tyres 14.5-20
2-3
